Tube processing range

mm

Round tube: φ8 - φ240

Square tube: □8*8 - □240*240

Rectangular tube: each side 8-240

Range of incoming materials for tube

mm

1000-9000

Positioning precision of X/Y axis

m/min

±0.05

Repetitive positioning precision of X/Y axis

mm

±0.03

Speed of chuck

RPM

100

（When the tube weight increases, the motion parameters would be reduced correspondingly）

Max. linkage speed

m/min

120

（When the tube weight increases, the motion parameters would be reduced correspondingly）

Max. linkage acceleration

G

1.0

Maximum single tube weight

Kg

About 300

Tailing length

L

≥85mm （for single chuck clamping，manual loading mode，Suggested Tube length≤500mm，Tube weight≤5kg）

≥185mm（for double chuck clamping mode）

Machine dimensions  Length*Width*High

mm

About 13860x2530*2215mm

Number of phases

/

3

Rated voltage of power source

V

415V

Frequency

Hz

50/60Hz

Overall capacity/ Current

KVA/A

25.5KVA/51.5A(1500W)

33KVA/63A(3000W)

Optical

Laser generator

Raycus 3kw-CE

Auto-focus cutting head

HS-Klinge

Transmission

Precision rack

LEITESEN/J&T

High precision linear guide rail

LAPPING/JINGWEI

Reducer & gear

motoreducer

High speed servo motor and drive

Inovance

Mechanical

Mechanical platform

HSG

Automatic centering chuck

HSG

Control

Control system

HSG-X10000

Nesting software

TubesT

(Standard matching material does not meet H-beam/I-beam nesting material)

Gas control proportional valve

MOOXEE（≤3KW)

External

Water chiller

Standard

Installation kits

Standard

Laser Head

Focusing Accuracy up to 0.01mm

With close-loop motor installed inside the laser head, the focus speed is much faster than market level to achieve higher piercing speed in high thickness materials.

Full Protection Inside & Outside

Equipped with double bottom protective lens inside, extending the lifetime of main lens. Equipped with stainless steel cover outside, protect the lines from laser flares.

Control System

With less than 100 microseconds processing response time, the bus control system can monitor real-time machine bed, lasers, water-cooling machine and cutting head, and satisfy the demand of specific functions from customers. Standard nesting software can improve utility of materials and has functions of tube splicing, precision control of laser energy, intelligent leapfrog technique, tube centering and others.

UNLOADING TABLE SUPPORT TYPE AUL30-F-R2

parameters:

Round tube diameter: 8-240mm;

Square tube side length: 8-240mm;

Max weight of pipe: 300kg;

Pipe length: ≤3000mm;

Overall capacity/ Current： 1KVA/2A
